Cable Tray Assistant Plugin is a must-have AutoCAD Plant 3D plugin explicitly designed to enhance the functionality of cable tray and support modeling tools previously published by us. If you’re already using these tools, you’ll soon realize the need for a more robust and user-friendly modeling environment. Tray Assistant is the perfect solution for elevating your designs by improving workflow efficiency and precision.
Cable Tray Assistant Plugin
$99.00
Cable Tray Assistant Plugin is a must-have AutoCAD Plant 3D plugin explicitly designed to enhance the functionality of cable tray and support modeling tools previously published by us. If you’re already using these tools, you’ll soon realize the need for a more robust and user-friendly modeling environment. Tray Assistant is the perfect solution for elevating your designs by improving workflow efficiency and precision.
Version 1.1.0:
- All components were included in tray commands (where the command requires selection of multiple or all components), and the command operation is applied to all of them, whether the component is hidden or even on the locked or invisible layer. This has now been updated. Only visible and editable components (i.e., unlocked) are included in the operations of every tray command. This feature gives more robust control to the user.
- Fuse Connection command was successfully fusing the components, but the fused connectors were placed on the active layer, which was causing issues in the generation of Isometric drawings. The issue has now been fixed. The fused connectors remain in the layer where their components reside.
- Export features encountered an error when the collection of exportable components included PIPE in this list. The issue is now fixed. Now, even if the PIPE or other PIPING Components (other than the tray, of course) are selected, then the export command will export only tray components and skip the rest. This has allowed users more control and flexibility. The user can simply Select All (Ctrl + A) and export.
- The uninstaller was removing the Settings File from the system, which was not an issue if the user decided to uninstall the program. However, when a new version is released and the user intends to upgrade, the new version installer first uninstalls the previous version and consequently deletes the Setting File, which is an undesirable behavior. The installer is now updated. Now, when the user uninstalls or updates to a newer version, the installer shall prompt for consent to retain or remove the Settings File. This upgrade has given users the authority to choose whether to retain or delete the Setting File.
- As we constantly provide our users with new features in our plugins, compatibility with older versions was felt necessary, especially since Cable Tray Assistant works on Cable Tray and Support plugins. To achieve this, a compatibility listener has been added to the plugin commands. The minimum version threshold is currently set to v1.6.1 for Cable Tray and v1.0.1 for the Support plugin. If the user has not yet upgraded to newer versions of the respective plugins and has installed the upgraded version of Cable Tray Assistant, this upgrade would work within the boundaries of the older versions of those plugins. However, if the user has already upgraded these plugins beyond their minimum threshold, the Cable Tray Assistant would work with the re-defined boundaries and upgrades of these plugins.
Version 1.0.0:
- First release of the plugin
- Include the interactive GUI in terms of a separate Panel on the AutoCAD Ribbon
- Custom Commands operation to streamline your Tray and Support design work.
- Capability of preserving your settings across sessions while using AutoCAD, so no worries about resetting everything every time
- Capability of exporting your tray components’ data in Excel sheets
- Content Rich Help document
This product is compatible with versions 2022, 2023, 2024, 2025, and 2026
- Enhance Cable Tray Auto-Placement: Tray Assistant seamlessly integrates with our Tray and Support plugins, automating the modeling process with precision and ease. Save hours of manual placement by auto-routing trays like pipes, adjusting segment lengths as desired, extending trays directly from existing components’ anchor points, auto-renaming components for unique BOM identification, and exporting your data in properly formatted Excel sheets.
- Customization Options: Tailor Tray Assistant’s features to your specific needs. The plugin remembers your settings, ensuring that you can pick up right where you left off in multiple sessions without losing any configurations.
- Intuitive User Interface: Tray Assistant adds interactive buttons to your Ribbon for an easy and efficient workflow.
- Content-Rich Support: Tray Assistant is packed with detailed help materials accessible directly from the Ribbon. Visualize each function’s workflow through short video demos, and access the relevant sections of the help document to guide you through every step.
Important Note:
- Tray Assistant isn’t a standalone tool. Instead, it’s a powerful assistant that amplifies the capabilities of our Parametric Cable Tray Plugin and Parametric Cable Tray Support Plugin. It enables you to model cable trays and their supports faster, more accurately, and with greater ease. Perfect for designers and engineers, Tray Assistant takes your workflow efficiency, design accuracy, and project deliverability to new heights.
- This plugin uses a custom installer (and not the standard App Store installer)
We have designed this product purchase system to ensure you stay in sync with our product updates on the Autodesk App Store. This payment gateway offers an alternative purchasing method for customers who are unable to use PayPal, the standard payment platform on Autodesk. It is essential that your purchase here is also synchronized with your account on the Autodesk App Store.
To achieve this, please follow these instructions precisely:
- If you don’t already have an account on the Autodesk App Store, please create a new account
- If you have no history of app downloads on the Autodesk App Store (paid or free), we will be unable to synchronize your purchase with the App Store. Don’t worry, the process is simple and quick. You just need to log in to your account and download any product that you like. It doesn’t matter which one you choose, but we recommend selecting one of the free apps so it won’t cost you anything. Once you click on download, Autodesk will display a pop-up message with the End-User License Agreement (EULA). Please read and accept this agreement. This process enrolls your account into Autodesk’s trusted client list, allowing us to bind your purchase on our site to the Autodesk App Store database. The video below shows this process for your reference.
- When you make a purchase on our site, please provide your verified Autodesk Account ID as mentioned above. You can leave it in the order notes on our checkout page. This is required to bind your purchase with Autodesk.
- After successful binding, you will receive an email from Autodesk (sent to the account you registered) confirming your download entitlement for our app. You can then visit the store page and see the download button enabled for you.
