Products
Showing all 3 results
-
Cable Tray Assistant Plugin
$99.00Add to cartCable Tray Assistant Plugin is a must-have AutoCAD Plant 3D plugin explicitly designed to enhance the functionality of cable tray and support modeling tools previously published by us. If you’re already using these tools, you’ll soon realize the need for a more robust and user-friendly modeling environment. Tray Assistant is the perfect solution for elevating your designs by improving workflow efficiency and precision.
-
Parametric Cable Tray Plugin
$99.00Add to cartThis plugin enhances your ability to design 3D cable tray systems within your existing projects, enabling you to simulate designs, assess route optimizations, generate precise isometric drawings, and provide immersive virtual tours to clients. It supports four tray categories: Ladder, Solid, Ventilated, and Wire Mesh (Wire Basket), each equipped with 13 essential components. These components are fully parametric, allowing real-time adjustments to their geometry to perfectly align with your project requirements.
-
Parametric Cable Tray Support Plugin
$59.00Add to cartThis plugin provides users with 3D models of in-actual tray support within existing projects, enabling them to visualize complete tray design. They can also identify potential clashes, generate isometric drawings, and provide virtual tours. The supports are per industrial standards and available in the three known categories i.e. Wall-Mounted, Ceiling-Hanged, and Floor-Mounted. The supports are fully parametric and allow real-time adjustments per the project’s needs.
